LC-LC SM Uniboot Optic Fiber Patch Cord

  • Category: Fiber Patch Cord
  • Source: LC-LC SM Uniboot Optic Fiber Patch Cord
  • Driver: HuiGoo Optic Co.,Limited
  • Housing: LC-LC SM Uniboot Optic Fiber Patch Cord

Inquiry now

or

Send email

We highly appreciate your feedback.
TEL: +86-013510362835
E-mail: sales@huigoooptic.com

                                                                LC-LC SM Uniboot Optic Fiber Patch Cord

Description:

LC-LC SM 1M Uniboot Optic FiberPatch Cord is a kind of insert an extraction connector based on the single coreplug  and adaptor, according to the jointcan be classified to type SC, SC,LC,ST, ,MU,MPO,MTRJ,E200 and so on, accordingto difference of the end face have the type PC,UPC , APC and so on.

Features:

Low insertion loss

high return loss

Durability ≤0.2dB after 1000cycles

High credibility and stability

Good in repeatability andexchangeability



Application:

Data center

Testing equipment

FTTX+LAN

Optical fiber CATV

Telecommunication



Details:



Model Number

Connector

Cable Jacket

Fiber Type

Cable Color

LC LC uniboot DX 1M

LC UPC uniboot DX

PVC/LSZH/OFNP

G675A1

Yellow / Orange / aqua


Specification:

Parameter

Unit

FC, SC, LC

ST, MU

MT-RJ, MPO

E2000

SM

MM

SM

MM

SM

MM

SM

PC

UPC

APC

PC

PC

UPC

PC

PC

UPC

PC

PC

APC

Insertion loss(typical)

dB

≤0.3

≤0.2

≤0.3

≤0.2

≤0.3

≤0.2

≤0.2

≤0.3

≤0.2

≤0.2

≤0.3

≤0.3

Return loss

dB

≥45

≥50

≥60

≥30

≥45

≥50

≥30

≥45

≥50

≥35

≥55

≥75

Operating wavelength

nm

1310, 1510

1310, 1510

1310, 1510

1310, 1510

Exchangeability

dB

≤0.2

≤0.2

≤0.2

≤0.2

Vibration

dB

≤0.2

≤0.2

≤0.2

≤0.2

Operating temperature

-40~75

-40~75

-40~75

-40~75

Storage temperature

-45~85

-45~85

-45~85

-45~85

Cable diameter

mm

φ3.0, φ2.0, φ0.9

φ3.0, φ2.0, φ0.9

φ3.0, φ2.0, φ0.9

φ3.0, φ2.0, φ0.9



Ordering Information:

Connector Type

FC,SC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4

Ferrule End-face

PC,UPC,APC

Core Type

Single-mode(SM:9/125μm),Multimode(MM:50/125μm or 62.5/125μm)

Cable Quantity

“SX”means simplex,”DX”means duplex;

Cable Diameter

Φ3.0mm,Φ2.0mm,Φ0.9mm;

Cable Length

Φ3.0mm,Φ2.0mm,Φ0.9mm

Cable Jacket

PVC, LSZH,OM3,OFNR

Fiber Type

G652D,G657A1,G657A2,G655....


If you are interested for our products, pls feel free to contact us. TEL:+86-013510362835. Email: sales@huigoooptic.com
