1x2 PLC Fiber Splitter, Splice/Pigtailed ABS Module, 2.0mm, LC/UPC

  • Category: Optical Splitter
  • Source: 1x2 PLC Fiber Splitter
  • Driver: HuiGoo Optic Co.,Limited
  • Housing: 1x2 PLC Fiber Splitter

Inquiry now

or

Send email

We highly appreciate your feedback.
TEL: +86-013510362835
E-mail: sales@huigoooptic.com

                               1x2 PLC Fiber Splitter, Splice/Pigtailed ABS Module, 2.0mm, LC/UPC

             HuiGoo provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE-2001 and GR-1221-CORE-1999 requirements.

             HuiGoo Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting.

Features
  • Low Insertion loss
  • Low PDL
  • Excellent Environmental & Mechanial Stability
  • Qualified Under Telcordia GR-1221 and GR-1209
Applications
  • FTTX (FTTP, FTTH, FTTN, FTTC)
  • Passive Optical Networks (PON)
  • Local Area Networks (LAN)
  • Cable Television
  • Test Equipments
Performance Specifications
ParameterSpecification
Operating Wavelength (nm)1260--1650
Type1x41x81x162x161x322x32
Insertion Loss (dB) Max.≦7.3≦11.0≦14.0≦14.3≦18≦18.8
Uniformity (dB) Max.≦1.0≦1.0≦1.5≦2.5≦2.0≦2.5
PDL (dB) Max≦0.3≦0.3≦0.4≦0.4≦0.45≦0.45
Dimensions (H*W*L)(nm)4x4x384x4x404x5x504x7x604x7x604x7x70
Directivity (dB) Min55
Return Loss (dB) Min50
Operating Temperature (℃)-40~+85
Storage Temperature (℃)-40~+85
Fiber Length1 m or custom length
Fiber TypeCorning singlemode SMF-28
Connector TypeCustom specified
Specifications may change without notice
Ordering information
PortWavelength (nm)Input Pigtall StyleInput ConnectorOutput Pigtal StyleFiber LengthOutput ConnectorPackage tube type
102=1x2
104=1x4
108=1x8
116=1x16
132=1x32
164=1x64
204=2x4
208=2x8
216=2x16
232=2x32
264=2x64
01=1260~1650
02=1310
03=1550
04=1310&1550
05=1310&1490&1550
0=none
1=900um Loose tube
2=900um Jacket
3=2.0cable
4=3.0cable
0=none
1=SC/PC
2=SC/APC
3=FC/PC
4=FC/APC
5=ST
6=LC
7=LC/APC
8=E2000
S=Special
0=none
1=900um Loose tube
2=900um Jacket
3=2.0cable
4=3.0cable
0=0.5m
1=1m
2=1.5m
3=2m
4=3m
5=4m
S=special
0=none
1=SC/PC
2=SC/APC
3=FC/PC
4=FC/APC
5=ST
6=LC
7=LC/APC
8=E2000
B1=100x80x10
B2=120x80x18
B3=142x102x14.5
B4=141x115x18
RT=19”1U Rack
SP=Special

If you are interested for our products, pls feel free to contact us. TEL:+86-013510362835. Email: sales@huigoooptic.com
